C-300 TFK Metal Fireplace with Log Rack FM

FM C-300 TFK wood-burning fireplace with turbine

A brick fireplace involves a project, builders, weeks of dust, and a budget that's almost never met. The C-300 TFK from FM Calefacción offers the same aesthetic result—fireplace, hood, and flue integrated into a single unit that spans the wall from floor to ceiling— without any masonry work . It arrives fully assembled and can be installed in a day.

Telescopic trim: adapts to your roof

The telescopic trim on the outlet pipe adjusts the overall height of the unit between 241.5 and 290 cm . This range of almost half a meter covers virtually any domestic ceiling height, so you don't need custom-made parts or makeshift finishing touches: the finish is clean from day one.

Tangential fan of 265 m³/h

A fireplace without forced ventilation heats up quickly in front of it but not much in the rest of the room. The 265 m³/h 43 W (220 V) tangential fan draws warm air into the room, equalizing the temperature much faster. It features a two-speed switch and an off position (0), allowing you to choose between power or quiet operation depending on the situation.

Draft diverter valve and combustion control

The draft diverter valve allows you to regulate the flue's draft: essential for controlling the combustion rate and preventing the wood from burning too quickly in systems with strong draft. Along with the independent primary and secondary air controls , it gives you fine-tuning how and how much each load burns.

Casting throughout the chamber

The combustion chamber, door, and grate are made of cast iron . Cast iron is the material with the highest thermal inertia: it retains heat and continues to release it even when the fire dies down, and it withstands repeated heating and cooling cycles without warping. The body is constructed of sheet metal up to 4 mm thick .

Rotating barbecue grill included

The C-300 TFK doesn't just heat up: it comes with a 310 x 300 mm stainless steel rotating grill . Cook meat, vegetables, or fish using the heat of the wood, without installing anything else.

Clean glass and a durable finish

The screen-printed ceramic glass withstands temperatures up to 750°C and incorporates a clean-glass system : an air curtain sweeps across the inner surface of the glass, delaying soot buildup so the flame remains visible without constant cleaning. The exterior is coated with inorganic heat-resistant paint that withstands temperatures up to 800°C .

Main features

• Fireplace aesthetics without masonry work
• Adjustable telescopic trim from 241.5 to 290 cm
• Tangential fan 265 m³/h 43 W (220 V)
• Two-speed switch with off mode
• draft diverter valve
• Interior of chamber, door and cast iron grill
• Body made of sheet metal up to 4 mm thick
• Dual combustion system
• Primary and secondary air regulation
• Crystal-clean system
• Screen-printed vitroceramic glass up to 750 ºC
• Inorganic heat-resistant paint up to 800°C
• Complies with Ecodesign regulations

Package contents

• C-300 TFK wood-burning fireplace with telescopic trim
• Rotating stainless steel barbecue grill (310 x 300 mm)
• Glove

Technical specifications

Before purchasing: Measure your ceiling height and ensure it falls within the range of 241.5 to 290 cm; outside this range, the unit will not fit. The fan requires a 220V power outlet near the unit. Ventilation requires a 200 mm diameter duct to the roof, and the manufacturer's safety distances from combustible materials must be observed. We recommend professional installation.

The Ø 200 mm tubes, elbows and cap are sold separately.
