C-203 K Three-Sided Metal Fireplace with Log Rack FM

FM C-203 K wood-burning fireplace with three-sided glass

A brick fireplace involves a project, builders, weeks of dust, and a budget that's almost never met. The C-203 K from FM Calefacción offers the same aesthetic result without any masonry work , and adds something few metal fireplaces provide: three-sided glass . The fire can be viewed from the front and both sides.

Panoramic view of the fire

The three-sided glazing completely transforms the relationship with the fireplace. There isn't just one good spot in the living room: the flame is visible from virtually any angle, and the fireplace acts as a visual focal point rather than an eyesore. The clean-glass system operates on all three sides , ensuring they remain equally transparent.

Classic design with wood storage

Beneath the fireplace, the integrated log storage keeps the day's load visible and within easy reach. Besides eliminating the need for floor baskets, the stacked firewood contributes to the classic aesthetic of this model and dries out with the residual heat from the fire.

A real home: 75 cm of trunk

The loading opening measures 665 x 370 mm and the firebox is 435 mm deep , accommodating logs up to 75 cm long . You can buy firewood in any standard size without cutting it, and each load lasts longer. A firebox of this size also produces a substantial flame, which is a key feature of a fireplace.

Double hood: more heat used

The double chimney creates an air chamber around the firebox. Instead of letting all the heat rise directly through the flue, this intermediate volume retains the heat and returns it to the room by convection. This is the key to this fireplace achieving an efficiency of 76.38% , well above that of a traditional open fireplace.

Vermiculite, double combustion and draft diverter

The interior of the combustion chamber is lined with vermiculite , a refractory material that reflects heat inwards instead of absorbing it, raising the combustion temperature. At these temperatures, the double combustion system reburns the gases that would otherwise be lost through the chimney. The draft diverter valve and independent primary and secondary air regulation give you fine control over the rate of combustion for each load.

Casting and durable finish

The door and grill are made of cast iron , the material that best withstands repeated heating and cooling cycles without warping. The body is constructed of sheet metal up to 4 mm thick , with inorganic heat-resistant paint that withstands temperatures up to 800°C , and the glass is screen-printed vitroceramic rated for 750°C .

Rotating barbecue grill included

The C-203 K doesn't just heat up: it comes with a 310 x 300 mm stainless steel rotating grill . Cook meat, vegetables, or fish using the heat of the wood, without installing anything else.

Main features

• Three-sided glass with a clean-glass system on all three sides
• Classic design with integrated log storage
• Fireplace aesthetics without masonry work
• Accepts logs up to 75 cm
• Double hood for better heat utilization
• Combustion chamber lined with vermiculite
• Cast iron door and grill
• Body made of sheet metal up to 4 mm thick
• Dual combustion system
• draft diverter valve
• Primary and secondary air regulation
• Screen-printed vitroceramic glass up to 750 ºC
• Telescopic trim for the outlet pipe
• Inorganic heat-resistant paint up to 800°C
• Complies with Ecodesign regulations

Package contents

• C-203 K wood-burning fireplace with telescopic trim
• Rotating stainless steel barbecue grill (310 x 300 mm)
• Glove

Technical specifications

Before you buy: Because this model has glass sides, it needs to be placed where those sides are visible; if installed in a niche or between furniture, it loses its main advantage. Ventilation requires a 250 mm diameter flue to the roof—a larger diameter than usual, requiring specific and more expensive pipes—and the safety distances from combustible materials specified by the manufacturer must be observed. We recommend that installation be carried out by a qualified professional.

Logistics note: Weighing 153 kg and measuring 95 cm in width, please ensure that access to your home is suitable for delivery before placing your order. Pipes, elbows, and Ø 250 mm caps are sold separately.
