C-200 RH Corner Metal Fireplace FM

Corner wood-burning fireplace with oven FM C-200 RH

The FM Calefacción C-200 RH is the most complete unit in the catalog: a corner design to make the most of the living room corner, the aesthetics of a brick fireplace without the masonry work, 19 kW for 363 m³ , and above the firebox, a full-size wraparound oven with a removable stainless steel interior. It heats the house and cooks with the same fire.

19 kW: the highest power in the range

With 19 kW of heat output , this fireplace transcends mere decoration and becomes a primary heating source. It's the ideal choice for country houses, homes with high ceilings, or open-plan spaces where a 10 or 12 kW unit simply won't provide enough heat.

A real oven, not a compartment

With a 600 x 430 mm opening and a depth of 540 mm , this oven accommodates full-size domestic trays: a lamb, several loaves of bread, or a whole batch of vegetables. It's a top-loading, surround oven , meaning the hot fumes circulate around the oven before exiting through the flue, resulting in even cooking on all sides instead of heating only from below.

Removable stainless steel interior

The oven interior is made of stainless steel and is completely removable . This is a key difference compared to a fixed oven: you can take it out for thorough cleaning after a greasy roast, instead of working blindly inside a hot, cramped cavity. The refractory brick base retains heat and distributes it evenly, and the probe thermometer allows you to monitor the temperature without opening the door.

Exceptional hearth: 80 cm logs

The loading opening measures 665 x 370 mm and the chamber is 475 mm deep : space for logs up to 80 cm long , a size very few domestic models can accommodate. You can buy firewood in any commercial format without cutting it, load several pieces at once, and keep the oven at a suitable temperature for much longer.

82.62% yield

The combustion chamber is lined with vermiculite , a refractory material that reflects heat inwards instead of absorbing it, raising the combustion temperature. At these temperatures, the double combustion system reburns the gases that would otherwise be lost through the flue. The result is an efficiency of 82.62% , the highest in the entire range, with a consumption of only 3.29 kg/h despite its 19 kW output.

anti-soot register and fine control

The soot trap facilitates regular flue maintenance, which is especially important in a unit with a wrap-around oven, where the flue gas path is longer. The draft diverter valve and independent primary and secondary air regulation give you precise control over the rate of each load.

Casting and durable finishes

The door and grill are made of cast iron , the material that best withstands repeated heating and cooling cycles without warping. The body is constructed of sheet metal up to 4 mm thick , with inorganic heat-resistant paint up to 800°C and 750°C screen-printed ceramic glass with a clean-glass system. The custom-made trim completes the installation with a clean finish.

Everything you need to cook, including

The unit comes with a 600 x 400 x 60 mm stainless steel tray that fits the oven and a 310 x 300 mm stainless steel rotating roasting rack . No separate accessories are required.

Main features

• Corner design that takes advantage of the angle of the living room
• 19 kW of heat output
• 600 x 430 mm wrap-around top oven
• Removable stainless steel oven interior
• Oven base made of refractory brick
• Sheath thermometer
• anti-soot register
• Accepts logs up to 80 cm
• Fireplace aesthetics without masonry work
• Combustion chamber lined with vermiculite
• Cast iron door and grill
• Body made of sheet metal up to 4 mm thick
• Dual combustion system
• draft diverter valve
• Primary and secondary air regulation
• Crystal-clean system
• Screen-printed vitroceramic glass up to 750 ºC
• Custom-made trim
• Inorganic heat-resistant paint up to 800°C
• Complies with Ecodesign regulations

Package contents

• Corner wood-burning fireplace with oven C-200 RH and trim
• Stainless steel baking tray (600 x 400 x 60 mm, 0.8 mm thick)
• Rotating stainless steel barbecue grill (310 x 300 mm)
• Glove

Technical specifications
