M-180 LK Wood Stove with Log Rack FM

FM M-180 LK Wood Stove with Log Storage

The FM Calefacción M-180 LK is the flagship model in the family: 17.6 kW for 340 m³ , a loading door that can handle 75 cm logs, and an integrated log storage compartment beneath the combustion chamber. All this with understated lines that make it a stylish addition to any room, not an appliance that needs to be hidden away.

75 cm logs: fewer refills

The loading opening measures 660 x 330 x 405 mm and accommodates logs up to 75 cm in length , an unusual size. In practice, this means two things: you can buy firewood in any commercially available size without cutting it, and each load lasts longer, so you open the door less often and the temperature in your home remains more stable.

Integrated wood storage

The wood storage unit is part of the equipment , housed beneath the combustion chamber. You have the day's load at hand, without baskets or piles on the floor, and the wood dries with the residual heat: drier wood means better combustion and less soot in the flue.

Hanging or on a bench

This model allows for two installation methods : wall-mounted or placed on a built-in base. This flexibility lets you adapt it to the project rather than the other way around, which is especially useful in renovations where there is already a niche or fireplace mantel.

Vermiculite and double combustion: 81% efficiency

The interior of the combustion chamber is lined with vermiculite , a refractory material that reflects heat inwards instead of absorbing it. At these high temperatures, the double combustion system burns gases that would otherwise be lost up the chimney. The result: 81% efficiency with a consumption of 3.68 kg/h.

Eco-design with very low emissions

The European Ecodesign Directive imposes strict efficiency and emissions limits on solid fuel appliances. The M-180 LK not only meets these requirements, but its CO2 emissions of 0.07% are among the lowest in its class. In addition to its environmental benefits, this certification is often a requirement for accessing subsidies for replacing heating equipment.

Clean glass and a durable finish

The screen-printed glass withstands temperatures up to 750°C and incorporates a clean-glass system : an air curtain sweeps across the interior surface of the glass, delaying soot buildup so the flame remains visible without constant cleaning. The exterior is coated with inorganic heat-resistant paint that withstands temperatures up to 800°C .

Main features

• Wood storage integrated under the camera
• Accepts logs up to 75 cm
• Hanging or bench installation
• Body made of sheet metal up to 4 mm thick
• Combustion chamber lined with vermiculite
• Dual combustion system
• Screen-printed glass up to 750 ºC
• Crystal-clean system
• Inorganic heat-resistant paint up to 800°C
• Upper flue outlet of Ø 200 mm
• Complies with Ecodesign regulations

Package contents

• M-180 LK wood stove with log storage
• Glove

Technical specifications

Before you buy: Weighing 147 kg, this unit requires a wall with sufficient load-bearing capacity and suitable anchors for hanging installation. Consult a professional if you have any doubts about your wall. Ventilation requires a 200 mm diameter flue—not 150 mm—and the manufacturer's specified safety distances from combustible materials must be observed. Pipes, elbows, and caps are sold separately.
