BH-180 P Insertable Wood Barbecue FM

€804.17

FM Heating model BH-180 P 80cm built -in barbecue with door. Unlike the open version, it features a cast iron door , allowing the combustion chamber to be closed and combustion controlled. Made of up to 4mm thick carbon steel with an 800°C heat-resistant paint finish, it includes a cast iron grate in the combustion chamber and comes with a stainless steel barbecue grill . It can be used with wood or charcoal and accommodates logs up to 70cm. It also includes a removable ash drawer, primary air regulator, draft diverter valve, and removable baffle. The flue outlet is Ø 200mm.

qty

compare
Rating:
(0)

Minimum price guaranteed


Security policy



Delivery policy



Return policy

FM BH-180 P Home Barbecue with Door

The FM Calefacción BH-180 P is the metal core for building your brick barbecue, in its version with a cast iron door . This 80 cm firebox is designed to be embedded in a brick or stone enclosure and is made of carbon steel up to 4 mm thick , capable of withstanding years of intensive use with both wood and charcoal.

The cast iron door makes all the difference

Being able to close the firebox completely changes how you use the barbecue. With the door closed, air only enters through the channels you control with the regulator, allowing you to slow down combustion and make much better use of each load of wood. It also contains sparks and smoke when you're not cooking, and gives the whole setup a cleaner, more enclosed look. Cast iron is the material that best withstands heating and cooling cycles without warping.

Robust construction

The 4 mm thick sheet metal is what separates a barbecue that lasts for decades from one that warps in a couple of seasons. The combustion chamber incorporates a cast iron grate , and the entire assembly is finished with 800°C heat-resistant paint .

Stainless steel grill included

It comes with a trapezoidal stainless steel grill (67 cm wide at the front, 52 cm wide at the back, and 40 cm deep), designed to fit the geometry of the firebox. Stainless steel won't rust outdoors or impart any flavors, and it makes use of virtually the entire usable surface area of the firebox.

Firewood or charcoal, logs up to 70 cm

The loading opening measures 34 x 68 cm and the chamber is 49 cm deep , accommodating logs up to 70 cm long . You can use commercially available firewood and create your own embers, or use charcoal for convenience. Primary air regulation and a draft diverter valve complete the combustion control system.

Removable deflector and easy cleaning

The baffle is removable , making it easy to adjust the draft and access the flue for regular cleaning. The removable ash drawer collects ash and grease during cooking and is emptied by simply pulling out the tray, without having to scrape the bottom of the chamber.

Main features

  • 80cm cast iron barbecue fireplace with door, for built-in installation
  • Made of carbon steel up to 4 mm
  • Cast iron grate in the combustion chamber
  • Stainless steel barbecue grill included
  • Suitable for firewood and charcoal
  • Accepts logs up to 70 cm
  • Removable ashtray drawer
  • Primary air regulation
  • draft diverter valve
  • Removable deflector
  • 800 ºC anti-heat paint
  • Flue outlet of Ø 200 mm

Package contents

  • BH-180 P Home Barbecue
  • Stainless steel barbecue grill (67 / 52 x 40 cm)
  • Glove

Optional accessories

  • Black anti-heat paint spray 800 ºC, 375 ml (non-rust)
  • Anti-drip sleeve Ø 200 mm in vitreous enamel black

Technical specifications

Manufacturer FM Heating
Model BH-180 P
Reference 709C04
EAN 8427561023675
Guy Built-in cast iron barbecue with door
Fuel Firewood and charcoal
Material Carbon steel up to 4 mm
Maximum trunk size 70 cm
Firewood inlet 34 x 68 cm
Camera depth 49 cm
Stainless steel grill included 67 / 52 x 40 cm
Smoke outlet Ø 200 mm
Fitting dimensions (H x W x D) 96.5 x 74 x 50 cm
Front panel dimensions (H x W) 63 x 81 cm
External dimensions (H x W x D) 96.5 x 81 x 58 cm
Weight 75 kg
Finish Black anti-heat paint 800 ºC

Manufacturer's warning: When using this equipment inside a home, it is recommended to install a forced extraction system to ensure proper gas evacuation.

BH-180-P-FM
100 Items

Data sheet

Weight
75 kg
Maximum log size
70 cm
Finish
Black anti-heat paint 800 ºC
Fuel
Firewood and charcoal
Smoke outlet
Ø 200 mm
Firewood inlet
49 cm
Frontal measurements
63 x 81 cm
Materials
Carbon steel up to 4 mm
Stainless steel grill
67 / 52 x 40 cm
Installation dimensions
96.5 x 74 x 50 cm
External dimensions
96.5 x 81 x 58 cm
