C-302 DK Metal Fireplace with Log Rack FM

€2,347.40

FM Calefacción model C-302 DK corner wood-burning metal fireplace, with a classic design and log storage, 10.4 kW nominal power (13.2 kW maximum) and a heating capacity of up to 295 m³. Its corner design makes use of often unused corners in living rooms, and it arrives fully assembled, requiring no masonry work. Made of steel up to 4 mm thick with a vermiculite- lined interior, cast iron door and grate, double combustion chamber, and removable ash drawer, it achieves 79% efficiency with only 0.10% CO emissions. It includes a 750°C screen-printed ceramic glass door, double combustion, and independent primary and secondary air controls. The flue outlet is Ø 200 mm.

Delivery in 7–10 business days

Use the discount code EXPO

Valid on non-discounted products.

qty

compare
Rating:
(0)

Minimum price guaranteed


Security policy



Delivery policy



Return policy

FM C-302 DK Corner Wood Burning Fireplace

Almost every living room has an unused corner. The FM Heating C-302 DK is designed to fill it: its angled shape fits perfectly into the corner without taking up valuable floor space, and offers the look of a traditional fireplace without the need for masonry work . It features a nominal output of 10.4 kW for 295 m³ and an integrated log storage compartment beneath the firebox.

79% efficiency: the best in the range of fireplaces

The interior of the combustion chamber is lined with vermiculite , a refractory material that reflects heat inwards instead of absorbing it, raising the combustion temperature. At these temperatures, the double combustion system burns the gases that would otherwise be lost through the flue. The result: 79% efficiency with a consumption of only 3.11 kg/h, figures closer to those of a stove than a conventional fireplace.

Very low emissions and Ecodesign certification

The European Ecodesign Directive imposes strict efficiency and emissions limits on solid fuel appliances. The C-302 DK easily meets these requirements: 0.10% CO₂ (at 13% O₂). In addition to its environmental benefits, this certification is often a requirement for accessing subsidies for heating equipment replacement.

Classic design with wood storage

Beneath the fireplace, the integrated log storage keeps the day's load visible and within easy reach. Besides eliminating the need for floor baskets, the stacked firewood contributes to the classic aesthetic of this model and dries out with the residual heat from the fire.

Double chamber and casting

The double chamber creates a volume of air around the firebox that retains heat and returns it to the room by convection, instead of letting it rise directly through the flue. The door and grille are made of cast iron , the material that best withstands repeated heating and cooling cycles without warping, and the body is constructed of steel up to 4 mm thick .

Fine combustion control

Independent primary and secondary air control allows you to adjust the combustion rate to match your chimney draft and the type of wood you use. The removable ash drawer allows you to empty the ashes by simply pulling out the tray, without soiling the floor.

Durable glass and finish

The screen-printed ceramic glass withstands temperatures up to 750°C , and the exterior is coated with heat-resistant paint that withstands temperatures up to 800°C . The total height of the unit is adjustable between 241.5 and 290 cm , a range of almost half a meter that covers virtually any domestic ceiling.

Main features

  • Corner design that makes the most of the space
  • Integrated woodshed with classic aesthetic
  • Fireplace aesthetics without masonry work
  • Vermiculite-coated inner chamber
  • Cast iron door and grille
  • Dual camera
  • Steel body up to 4 mm thick
  • Dual combustion system
  • Removable ashtray drawer
  • Primary and secondary air regulation
  • Screen-printed vitroceramic glass up to 750 ºC
  • Anti-heat paint up to 800 ºC
  • Adjustable height from 241.5 to 290 cm
  • Complies with Ecodesign regulations

Technical specifications

Manufacturer FM Heating
Model C-302 DK
Guy Corner metal fireplace with log storage
Fuel Firewood
Nominal power 10.4 kW
Maximum thermal power 13.2 kW
Heating volume 295 m³
Performance 79%
Consumption 3.11 kg/h
CO emissions (13% O₂) 0.10%
Average flue gas temperature 241 ºC
Firewood inlet 54.5 x 29.5 x 35 cm
Smoke outlet Male, Ø 200 mm
Total height From 241.5 to 290 cm (adjustable)
Width x Depth 82.5 x 56.1 cm
Weight 132 kg
Regulations Ecodesign (European Commission)

Before purchasing: measure your ceiling height and ensure it falls within the range of 241.5 to 290 cm; outside this range, the unit will not fit. As this is a corner model, it requires a clear corner with vertical flue space. Exhaust requires a 200 mm diameter flue to the roof, and the manufacturer's specified safety distances from combustible materials must be observed. We recommend professional installation.

Logistics note: Weighing 132 kg, please ensure that access to your home is suitable for delivery before placing your order. Pipes, elbows, and Ø 200 mm caps are sold separately.

C-302-DK-FM
100 Items

Data sheet

Nominal power
10.4 kW
Performance
79%
CO2 emissions
0.10%
Maximum Thermal Power (KW)
13.2 kW
Weight
132 kg
Height
From 241.5 to 290 cm (adjustable)
Fuel
Firewood
Consumption
3.11 kg/h
Smoke outlet
Male, Ø 200 mm
Heating volume
295 m³
Firewood inlet
54.5 x 29.5 x 35 cm
Average flue gas temperature
241 ºC
Width x Depth
82.5 x 56.1 cm
