C-300 RK Corner Metal Fireplace FM

€1,770.00

FM Heating model C-300 RK corner wood-burning metal fireplace, with a classic design and log storage, 10.9 kW nominal power (13.8 kW maximum) and a heating capacity of up to 285 m³. Its corner design makes the most of the living room's corners and it arrives fully assembled, requiring no masonry work. It features two ducted air nozzles to distribute heat to other rooms, a double combustion system with 79% efficiency and CO emissions of only 0.100%. The door is made of cast iron with fiberglass and a ceramic glass sealing ring, and the screen-printed glass is heat resistant up to 750°C. It accommodates 62 cm logs and includes a stainless steel rotating grill . The top male flue outlet is Ø 200 mm and also made of cast iron.

qty

compare
Rating:
(0)

Minimum price guaranteed


Security policy



Delivery policy



Return policy

FM C-300 RK Corner Wood Burning Fireplace

Almost every living room has an unused corner. The FM Calefacción C-300 RK is designed to fill it: its corner design fits perfectly into the angle without taking up valuable floor space, offering the look of a traditional fireplace without the need for masonry work . It boasts a nominal output of 10.9 kW for 285 m³ , an integrated log storage compartment, and a feature rarely seen in this type of fireplace: ducted air.

Two ductable air nozzles

This is the key difference. The two ductable air nozzles allow the hot air to be piped to other rooms in the house : a bedroom, a hallway, the upper floor. With them, the fireplace no longer heats only the living room but begins to function as a small distributed heating system, utilizing heat that would otherwise remain trapped under the ceiling.

79% efficiency and very low emissions

The double combustion system reburns gases that would otherwise escape unused up the chimney in a conventional fireplace. The result is 79% efficiency with a maximum fuel consumption of 3.16 kg/h and CO emissions of 0.100% (at 13% O₂), figures closer to those of a wood-burning stove than a traditional fireplace. Independent primary and secondary air control allows you to adjust the combustion rate to suit your chimney draft and the type of wood.

Cast iron door with airtight seal

The door is made of cast iron , the material that best withstands repeated heating and cooling cycles without warping. It also incorporates fiberglass and a ceramic glass sealing ring : this seals the door so that all the air enters through the channels you control with the regulators, and not through gaps. With a well-sealed door, the wood burns at the rate you set, not at the rate dictated by the draft.

Classic design with wood storage

Beneath the fireplace, the integrated log storage keeps the day's load visible and within easy reach. Besides eliminating the need for floor baskets, the stacked firewood contributes to the classic aesthetic of this model and dries out with the residual heat from the fire.

Rotating barbecue grill included

The C-300 RK doesn't just heat: it comes with a 310 x 300 mm stainless steel rotating grill . Cook meat, vegetables, or fish using the heat of the wood, without any additional installation. The firebox is 350 mm deep and accommodates logs up to 62 cm long .

Durable glass and finish

The screen-printed ceramic glass withstands temperatures up to 750°C , and the exterior is coated with black heat-resistant paint that withstands temperatures up to 800°C . The total height of the unit is adjustable between 241 and 290 cm , a range that covers virtually any standard ceiling.

Main features

  • Corner design that takes advantage of the angle of the living room
  • Two air nozzles that can be ducted to other rooms
  • Integrated woodshed with classic aesthetic
  • Fireplace aesthetics without masonry work
  • Cast iron door with fiberglass and ceramic glass cord
  • Dual combustion system
  • Primary and secondary air regulation
  • Rotating stainless steel grill for roasting, 310 x 300 mm
  • Screen-printed vitroceramic glass up to 750 ºC
  • Black anti-heat paint up to 800 ºC
  • Top male flue outlet of Ø 200 mm in cast iron
  • Adjustable height from 241 to 290 cm

Technical specifications

Manufacturer FM Heating
Model C-300 RK
Guy Corner metal fireplace with log storage and ducted air
Fuel Firewood
Nominal power 10.9 kW
Maximum power 13.8 kW
Heating volume 285 m³
Performance 79%
Maximum consumption 3.16 kg/h
CO emissions (13% O₂) 0.100%
Maximum flue gas temperature 241 ºC
Maximum trunk size 62 cm
Firewood inlet 545 x 295 mm
Camera depth 350 mm
Ducted air 2 nozzles
Smoke outlet Upper male, Ø 200 mm, in cast iron
Dimensions (W x D x H) 113 x 68 x 241-290 cm
Weight 132 kg

C-300-RK-FM
100 Items

Data sheet

CO emissions at 13% O2
0.100%
Performance
79%
Weight
132 kg
Maximum log size
62 cm
Nominal / maximum power
10.9 kW
Fuel
Firewood
Total power
13.8 kW
Dimensions (W x D x H)
113 x 68 x 241-290 cm
Smoke outlet
Upper male, Ø 200 mm, in cast iron
Heating volume
285 m³
Firewood inlet
545 x 295 mm
Camera depth
350 mm
Maximum consumption
3.16 kg/h
Maximum flue gas temperature
241 ºC
Ducted air
2 nozzles
