C-200 H Metal Fireplace with FM Oven

€2,430.00

FM Heating model C-200 H metal wood-burning fireplace with oven, 15 kW of power and capacity to heat up to 363 m³. It offers the aesthetic of a traditional brick fireplace without the need for masonry work and adds a large, wrap-around upper oven with a 600 x 430 mm opening, 420 mm depth, removable stainless steel interior, refractory brick base, and sheathed thermometer. Constructed of sheet metal up to 4 mm thick with a vermiculite-lined cavity, cast iron door and grate, and a double chimney, it accommodates logs up to 75 cm in length . It includes a draft diverter, soot trap, clean-glass system, telescopic trim, 600 x 400 mm stainless steel tray, and a rotating roasting grill. The flue outlet is Ø 250 mm.

qty

compare
Rating:
(0)

Minimum price guaranteed


Security policy



Delivery policy



Return policy

FM C-200 H wood-burning fireplace with oven

The FM Calefacción C-200 H is the most complete unit in the range of fireplaces: the aesthetics of a brick fireplace without masonry , 15 kW for 363 m³ , and, above the firebox, a full-size, wraparound oven with a removable stainless steel interior. It heats the house and cooks with the same fire.

A real oven, not a compartment

With a 600 x 430 mm opening and a depth of 420 mm , this oven accommodates full-size domestic trays: a lamb, several loaves of bread, or a whole batch of vegetables. It's a top-loading, surround oven , meaning the hot fumes circulate around the oven before exiting through the flue, resulting in even cooking on all sides instead of heating only from below.

Removable stainless steel interior

The oven interior is made of stainless steel and is completely removable . This is a key difference compared to a fixed oven: you can take it out for thorough cleaning after a greasy roast, instead of working blindly inside a hot, cramped cavity. The refractory brick base retains heat and distributes it evenly, and the probe thermometer allows you to monitor the temperature without opening the door.

Large hearth: 75 cm logs

The loading opening measures 665 x 370 mm and the chamber is 475 mm deep : space for logs up to 75 cm long. You can buy firewood in any commercially available format without cutting it and load several pieces at once, which extends the cooking time and keeps the oven at a suitable temperature for longer.

Double bell and double combustion

The interior of the chamber is lined with vermiculite , a refractory material that reflects heat inwards instead of absorbing it, raising the combustion temperature. At these temperatures, the double combustion system reburns the gases that would otherwise be lost through the flue, and the double hood retains the heat and returns it to the room by convection.

anti-soot register and fine control

The soot trap facilitates regular flue maintenance, which is especially important in a unit with a wrap-around oven, where the flue gas path is longer. The draft diverter valve and independent primary and secondary air regulation give you precise control over the rate of each load.

Casting and durable finishes

The door and grill are made of cast iron , the material that best withstands repeated heating and cooling cycles without warping. The body is constructed of sheet metal up to 4 mm thick , with inorganic heat-resistant paint up to 800°C and 750°C ceramic glass with a clean-glass system.

Everything you need to cook, including

The unit comes with a 600 x 400 x 60 mm stainless steel tray fitted to the oven and a 310 x 300 mm stainless steel rotating roasting rack . The telescopic exhaust pipe cover completes the installation with a clean finish.

Main features

  • 600 x 430 mm wrap-around top oven
  • Removable stainless steel oven interior
  • Oven base made of refractory brick
  • Sheath thermometer
  • anti-soot register
  • Accepts logs up to 75 cm
  • Fireplace aesthetics without masonry work
  • Double bell
  • Combustion chamber lined with vermiculite
  • Cast iron door and grill
  • Body made of sheet metal up to 4 mm thick
  • Dual combustion system
  • draft diverter valve
  • Primary and secondary air regulation
  • Crystal-clean system
  • Screen-printed vitroceramic glass up to 750 ºC
  • Telescopic trim for the outlet pipe
  • Inorganic heat-resistant paint up to 800°C
  • Complies with Ecodesign regulations

Package contents

  • Wood-burning fireplace with oven C-200 H and telescopic trim
  • Stainless steel baking tray (600 x 400 x 60 mm, 0.8 mm thick)
  • Rotating stainless steel barbecue grill (310 x 300 mm)
  • Glove

Technical specifications

Manufacturer FM Heating
Model C-200 H
Guy Metal fireplace with wrap-around upper oven
Fuel Firewood
Heat output 15 kW
Heating volume 363 m³
Performance 72%
Consumption 4.40 kg/h
CO2 emissions 0.25%
Maximum trunk size 75 cm
Firewood inlet 665 x 370 mm
Camera depth 475 mm
Oven mouth 600 x 430 mm
Oven depth 420 mm
Smoke outlet Ø 250 mm
Total height From 259 to 319 cm (telescopic)
Width x Depth 95 x 54 cm
Weight 180 kg
Regulations Ecodesign (European Commission)
C-200-H-FM
100 Items

Data sheet

CO2 emissions
0.25%
Heat output
15 kW
Performance
72%
Weight
180 kg
Maximum log size
75 cm
Height
From 259 to 319 cm (telescopic)
Fuel
Firewood
Consumption
4.40 kg/h
Smoke outlet
Ø 250 mm
Heating volume
363 m³
Firewood inlet
665 x 370 mm
Camera depth
475 mm
Width x Depth
95 x 54 cm
Oven mouth
600 x 430 mm
Oven depth
420 mm

Specific References
